Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker [7049]
What's in the Box? (Package Includes)
Factory Sealed- 1x Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker — Original Factory Package
- All standard accessories and hardware as packed by the manufacturer
- Manufacturer's documentation, warranty card, and instruction manual
For exact package contents, see the manufacturer's product page
7049 200 Amp Panel Mount 187 Series Circuit Breaker
Features:
- Combines switching and circuit protection into a single device*
- Clear, single lever operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Large Clearance around terminal studs accecpt heavy gauge wire lugs
- Robust 5/16 M8 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected - Safe for installation aboard gasoline powered boats
Specifications:
- Interrupt Rating - 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC
- Maximum Voltage Rating - 48 Volts DC
- Operating Temperature Range - -40xC to 85xC
- Circuit Breaker Type - Thermally responsive bi-metal blade
- Circuit Breaker Class - Type III - switchable/manual reset - trip free
- Terminal Stud Size - 5/16"-18
- Terminal Stud Torque - 75 in-lb
- Mounting Holes - Accept #10 (M5) Screw
- Weight Lb (Kg) - 0.50 (0.23)
- Case Material - Thermoset Polyester
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Specifications:
- Amperage: 200a
- Box Dimensions: 3"H x 5"W x 8"L WT: 0.5 lbs
- UPC: 632085070496
