Raymarine CAM400 Marine Day/Night IP Camera - White [E70716]
What's in the Box? (Package Includes)
Factory Sealed- 1x Raymarine CAM400 Marine Day/Night IP Camera - White — Original Factory Package
- All standard accessories and hardware as packed by the manufacturer
- Manufacturer's documentation, warranty card, and instruction manual
For exact package contents, see the manufacturer's product page
CAM400 Marine Day/Night IP Camera - White
The CAM400 is a rugged fixed-mount marine IP camera for above-deck and below-deck monitoring applications, designed for seamless integration with Raymarine Axiom or Axiom 2 chartplotters. It can be deployed as a standalone camera or as part of a multi-camera system, supporting flexible monitoring and viewing across connected displays and networked devices.
Use CAM400 to assist with close-quarters maneuvering, monitor blind spots, check on crew and passengers, or enhance onboard security. With integrated infrared illumination, CAM400 provides dependable image performance in daylight, low light, and nighttime.
Features:
- High-definition marine IP camera for Raymarine Axiom systems.
- Full HD 1080p video.
• Wide-angle 129° horizontal field of view.
- Optimized for docking, onboard monitoring, and security applications.
- Enhanced situational awareness;* pair with a Raymarine AR200 sensor to unlock augmented reality on your Axiom display.
- Overlay AIS targets, waypoints, and chart details directly onto the live video image.
- Integrated infrared illumination for low-light and nighttime awareness.
- Flexible installation options with Power over Ethernet (PoE) or 12 V DC.
- Multi-stream video support for integration with onboard systems.
- Image flip and invert functions for ball-up and ball-down mounting.
- Compact, low-profile design for discreet installation.
- Rugged, marine-grade construction for above-deck environments.
- Factory-installed RayNet® Ethernet pigtail with no waterproof RJ-45 coupler required.
- Optional on-screen distance lines when integrated with LightHouse 5 on Axiom 2 systems
In the Box:
- CAM400 - includes a 1.4 m (4.8 ft) integrated pigtail with PoE (RayNet) male, factory reset switch, and direct-power breakout
- Camera collar
- Documentation
- Camera base
- Mounting gasket (pre-fitted to the camera base)
- Hex wrench (Allen key)
- Bushings (3 x)
- Silicone rings (3 x)
- Flat washers (3 x)
- Grub screws (3 x)
- M4 x 30 mm self-tapping mounting screws (3 x)
Brochure (pdf)
| Brand / Manufacturer | Raymarine |
|---|---|
| Category / Product Type | Cameras - Network Video |
| MPN / Manufacturer Part # | HTS-115962 |
| Item Condition | 100% Brand New / Factory Sealed |
| Warranty Status | Full Original Manufacturer Warranty Backed |
| Fulfillment Hub | Dispatched from Regional Marine Distribution Hubs |
